一、系统目标

构建一套基于 Python 的集成化 Linux 服务器管理系统，实现对服务器全功能的统一管控，涵盖文件操作、SSH 配置、网络管理、Web 服务（Apache/Nginx）、防火墙（UFW）及 MySQL 数据库等核心模块，支持本地及远程服务器管理，提供直观的操作接口（CLI 或 Web）。

二、核心功能范围

覆盖 Linux 服务器管理全场景，具体包括：

1. 文件管理：本地/远程文件的创建、删除、复制、移动、权限修改、压缩/解压、内容编辑、磁盘占用分析等。
2. SSH 管理：SSH 服务状态监控、配置修改（端口、密钥认证、登录限制）、用户密钥管理、连接日志审计、批量执行命令等。
3. 网络管理：网卡配置（IP、子网掩码、网关）、DNS 设置、端口监听检测、网络流量监控、路由表管理、防火墙规则关联等。
4. Web 服务管理：

• Apache：服务启停/重启、虚拟主机配置、模块管理、日志分析、状态监控。
• Nginx：服务控制、配置文件校验、虚拟主机管理、反向代理配置、性能参数调优。

1. 防火墙（UFW）管理：防火墙状态切换、端口放行/封禁、IP 黑白名单设置、规则备份/恢复、状态监控。
2. MySQL 管理：服务启停、用户权限管理、数据库备份/恢复、性能参数配置、连接状态监控、日志分析。

三、系统架构设计

1. 整体架构

采用模块化分层设计，分为：

• 基础层：负责连接管理（本地/SSH 会话）、权限校验、日志记录、异常处理。
• 功能模块层：按管理对象拆分独立模块（文件、SSH、网络等），模块间低耦合。
• 接口层：提供 CLI 命令行接口（优先实现），预留 Web 接口扩展能力。
• 数据层：存储服务器配置信息、操作日志、备份策略等（支持本地文件或轻量数据库）。

2. 模块关系

• 所有功能模块依赖基础层的连接管理能力，通过统一接口执行本地/远程操作。
• 功能模块间可交叉调用（如：Web 服务管理需依赖防火墙模块配置端口放行）。
• 接口层聚合所有模块功能，提供统一的用户交互入口。

四、模块详细设计

1. 基础连接模块

• 核心能力：管理本地服务器直接操作、远程服务器 SSH 连接（支持密码/密钥认证）、连接池维护、会话保持。
• 关键特性：自动重连机制、操作超时控制、权限验证（确保执行用户有足够权限）。

2. 文件管理模块

• 本地文件操作：基于 Python 内置文件操作库，实现基础文件/目录管理、权限控制（映射 Linux chmod/chown）。
• 远程文件操作：通过 SFTP 协议实现文件上传/下载，执行远程命令实现权限修改、压缩（tar/zip）等。
• 高级功能：文件差异对比、批量文件操作、大文件断点传输、磁盘空间告警。

3. SSH 管理模块

• 服务配置：读取/修改 /etc/ssh/sshd_config，支持端口变更、禁用密码登录、限制root登录等配置项。
• 密钥管理：生成 SSH 密钥对、向远程服务器推送公钥（实现免密登录）、管理 authorized_keys 文件。
• 审计功能：解析 SSH 登录日志（/var/log/auth.log），统计登录次数、异常登录告警。

4. 网络管理模块

• 网卡配置：读取/修改网络接口配置文件（如 /etc/netplan/ 或 /etc/sysconfig/network-scripts/），支持静态IP/动态IP切换。
• 状态监控：执行 ifconfig/ip 命令获取网卡状态，netstat/ss 查看端口占用，ping/traceroute 检测网络连通性。
• 流量分析：通过 iftop 或解析 /proc/net/dev 监控实时流量，记录流量峰值。

5. Web 服务管理模块（Apache/Nginx）

• 服务控制：通过 systemctl 管理服务启停/重启/状态查询，支持配置文件语法校验。
• 虚拟主机管理：创建/删除虚拟主机配置文件、关联域名与目录、配置 SSL 证书路径。
• 性能监控：获取当前连接数、请求量、错误率（解析访问日志），支持重启策略（如请求量过高时自动重启）。

6. 防火墙（UFW）管理模块

• 规则管理：添加/删除端口允许规则（如允许 80/tcp）、IP 限制（如禁止特定IP访问）、规则优先级调整。
• 状态控制：启用/禁用防火墙、查看当前活跃规则、保存/恢复规则配置。
• 日志分析：解析 UFW 日志，统计拦截记录、异常访问模式识别。

7. MySQL 管理模块

• 服务控制：通过 systemctl 管理 MySQL 服务状态，配置开机自启。
• 数据库操作：执行 SQL 命令（创建库/表、增删改查）、管理用户权限（ grant/revoke）。
• 备份与恢复：定时生成数据库备份（mysqldump）、支持全量/增量备份，提供备份文件恢复接口。
• 性能监控：查看连接数、慢查询日志、缓存命中率，调整 my.cnf 中的性能参数（如 buffer_size）。

五、操作流程设计

1. 初始化：用户输入服务器信息（IP、端口、认证方式），系统建立连接并验证权限。
2. 功能选择：通过菜单或命令参数指定操作类型（如文件管理、防火墙配置等）。
3. 执行操作：系统调用对应模块处理，返回执行结果（成功/失败原因）。
4. 日志记录：所有操作自动记录（时间、用户、操作内容、结果），支持查询审计。

六、扩展与可靠性设计

• 批量管理：支持同时连接多台服务器，执行批量操作（如统一配置防火墙规则）。
• 容错机制：操作失败时自动回滚（如修改配置文件前备份原文件），网络中断后自动重试。
• 权限控制：区分管理员/普通用户权限，限制高危操作（如删除系统文件、关闭防火墙）。
• 跨发行版兼容：适配 Ubuntu（Debian 系）、CentOS（RHEL 系）等主流 Linux 发行版，处理配置文件路径差异。

七、交付形式

• 核心程序：Python 脚本集合（模块化组织）。
• 运行环境：Python 3.8+，依赖库包括 paramiko（SSH）、python-dotenv（配置管理）等。
• 文档：操作手册（含命令列表）、模块接口说明、扩展开发指南。

该方案通过模块化设计实现 Linux 服务器全功能管理，兼顾灵活性与易用性，可满足中小型服务器集群的日常运维需求。

1. System objectives

Build an integrated Linux server management system based on Python to achieve unified control of all server functions, covering core modules such as file operation, SSH configuration, network management, web services (Apache/Nginx), firewall (UFW), and MySQL database, support local and remote server management, and provide intuitive operation interfaces (CLI or Web).

2. Core functional scope

Covers all scenarios of Linux server management, including:

1. File management: create, delete, copy, move, modify permissions, compress/decompress, edit content, analyze disk occupancy, etc.
2. SSH management: SSH service status monitoring, configuration modification (port, key authentication, login restrictions), user key management, connection log auditing, batch command execution, etc.
3. Network management: NIC configuration (IP, subnet mask, gateway), DNS settings, port listening detection, network traffic monitoring, routing table management, firewall rule association, etc.
4. Web Services Management:

• Apache: Service start, stop/restart, virtual host configuration, module management, log analysis, and status monitoring.
• Nginx: Service control, profile validation, virtual host management, reverse proxy configuration, and performance parameter tuning.

1. Firewall (UFW) management: firewall status switching, port release/blocking, IP blacklist and whitelist settings, rule backup/recovery, and status monitoring.
2. MySQL management: service start and stop, user permission management, database backup/recovery, performance parameter configuration, connection status monitoring, and log analysis.

3. System architecture design

1. Overall architecture

It adopts a modular layered design and is divided into:

• Basic layer: Responsible for connection management (local/SSH sessions), permission verification, logging, and exception handling.
• Functional module layer: Split independent modules (file, SSH, network, etc.) according to management objects, and low coupling between modules.
• Interface layer: Provides CLI command-line interface (preferred) and reserves web interface extension capabilities.
• Data layer: Stores server configuration information, operation logs, backup policies, etc. (supports local files or lightweight databases).

2. Module relationships

• All functional modules rely on the connection management capabilities of the base layer to perform local/remote operations through a unified interface.
• Function modules can be cross-called (for example, Web service management relies on firewall modules to configure port release).
• The interface layer aggregates all module functions to provide a unified user interaction portal.

4. Detailed design of modules

1. Base connection module

• Core competencies: Manage direct operation of local servers, SSH connections to remote servers (support password/key authentication), connection pool maintenance, and session keeping.
• Key features: automatic reconnection mechanism, operation timeout control, permission verification (ensure that the executing user has sufficient permissions).

2. File management module

• Local file operation: Based on the Python built-in file operation library, basic file/directory management and permission control (mapping Linux chmod/chown) are realized.
• Remote file manipulation: Upload/download files through the SFTP protocol, and execute remote commands to modify permissions, compress (tar/zip), etc.
• Advanced features: file difference comparison, batch file operation, large file breakpoint transfer, and disk space alarm.

3. SSH management module

• Service configuration: Read/Modify, supports port change, disable password login, restrict root login, and other configuration items./etc/ssh/sshd_config
• Key management: Generate SSH key pairs, push public keys to remote servers (enable passwordless login), and manage files.authorized_keys
• Audit function: Parse SSH login logs () to count the number of logins and abnormal login alarms./var/log/auth.log

4. Network management module

• NIC configuration: Read/modify network interface configuration files (such as or ) to support static IP and dynamic IP switching./etc/netplan//etc/sysconfig/network-scripts/
• Status monitoring: Execute / command to obtain the status of the network card, / check port occupancy, / detect network connectivity.ifconfigipnetstatsspingtraceroute
• Traffic Analysis: Monitor real-time traffic through or parse to record traffic spikes.iftop/proc/net/dev

5. Web Services Management Module (Apache/Nginx)

• Service control: Supports configuration file syntax verification by managing service start-stop/restart/status query.systemctl
• Web hosting management: Create/delete web hosting profiles, associate domain names and directories, and configure SSL certificate paths.
• Performance monitoring: Obtain the current number of connections, request volume, and error rate (parse access logs), and support restart policies (such as automatic restart when the request volume is too high).

6. Firewall (UFW) management module

• Rule management: add/remove port allow rules (such as allowing 80/tcp), IP restrictions (such as prohibiting access to specific IPs), and adjust rule priority.
• Status control: Enable/disable firewall, view currently active rules, save/restore rule configurations.
• Log analysis: Parsing UFW logs, statistical interception records, and identifying abnormal access patterns.

7. MySQL management module

• Service control: Manage MySQL service status and configure boot autostart.systemctl
• Database operations: Execute SQL commands (create libraries/tables, add, delete, modify, and query) and manage user permissions (grant/revoke).
• Backup and recovery: Generate database backups (mysqldump) regularly, support full/incremental backups, and provide backup file recovery interfaces.
• Performance monitoring: View the number of connections, slow query logs, cache hit rate, and adjust performance parameters (such as buffer_size).my.cnf

5. Operation process design

1. Initialization: The user enters the server information (IP, port, and authentication method), and the system establishes a connection and verifies the permissions.
2. Function Selection: Specify the type of operation (such as file management, firewall configuration, etc.) through menus or command parameters.
3. Execution: The system calls the corresponding module to process and returns the execution result (success/failure reason).
4. Logging: All operations (time, user, operation content, and result) are automatically recorded, and query auditing is supported.

6. Expansion and reliability design

• Batch management: Supports connecting multiple servers at the same time to perform batch operations (such as uniformly configuring firewall rules).
• Fault tolerance mechanism: Automatically rolls back when the operation fails (for example, backing up the original file before modifying the configuration file), and automatically retries after network interruption.
• Permission control: Distinguish between administrator and ordinary user permissions and restrict high-risk operations (such as deleting system files and turning off firewalls).
• Cross-distribution compatibility: Compatible with mainstream Linux distributions such as Ubuntu (Debian series) and CentOS (RHEL series) to handle configuration file path differences.

7. Form of delivery

• Core program: Python script collection (modular organization).
• Running environment: Python 3.8+, dependency libraries include paramiko (SSH), python-dotenv (configuration management), etc.
• Documentation: Operation manual (including command list), module interface description, extension development guide.

This solution realizes full-function management of Linux servers through modular design, taking into account flexibility and ease of use, and can meet the daily operation and maintenance needs of small and medium-sized server clusters.
